Related products
-
PS-006 planetary gear table
Consisting of base plate for connection to the tilt and height adjustable specimen table of the CCU-010 base unit. Specimen holders for six large (Ø 25.4mm) or six small (Ø12.7mm) SEM pin stubs. DC micro-motor for rotation and planetary movement, quartz sensor (centre), speed control: 0-100%, rotation: 0-20rpm approximately, planets: 0-65rpm approximately
SKU: 1000130Price On Request £0.00 Add to basketAdd to QuoteWithin your QuoteAdd to QuotePS-006 planetary gear table
Consisting of base plate for connection to the tilt and height adjustable specimen table of the CCU-010 base unit. Specimen holders for six large (Ø 25.4mm) or six small (Ø12.7mm) SEM pin stubs. DC micro-motor for rotation and planetary movement, quartz sensor (centre), speed control: 0-100%, rotation: 0-20rpm approximately, planets: 0-65rpm approximately
£0.00Price On Request -
RS-010 rotary table
Plug-in style rotary specimen table with smooth adjustment of table height, tilt angle and rotational speed. The 80mm diameter stage has locations for up to 20 standard (13 mm) SEM pin stubs or five 25mm stubs. On request other sizes and styles of SEM stubs can be accommodated.
SKU: 100005Price On Request £0.00 Add to basketAdd to QuoteWithin your QuoteAdd to QuoteRS-010 rotary table
Plug-in style rotary specimen table with smooth adjustment of table height, tilt angle and rotational speed. The 80mm diameter stage has locations for up to 20 standard (13 mm) SEM pin stubs or five 25mm stubs. On request other sizes and styles of SEM stubs can be accommodated.
£0.00Price On Request -
Rotary support for PS-006
Rotary support for use with the PS-006 planetary gear stage. Includes slip-on specimen holder which converts the planetary gear stage into a rotary stage. Twelve M2 threads for mounting specimens or for the using S-clips. Six mounting clips M2 included.
SKU: 1000089Price On Request £0.00 Add to basketAdd to QuoteWithin your QuoteAdd to QuoteRotary support for PS-006
Rotary support for use with the PS-006 planetary gear stage. Includes slip-on specimen holder which converts the planetary gear stage into a rotary stage. Twelve M2 threads for mounting specimens or for the using S-clips. Six mounting clips M2 included.
£0.00Price On Request -
High vacuum (HV) upgrade kit I
Upgrade kit for converting CCU-010 LV to high vacuum CCU-010 HV specification. Includes turbomolecular pump (Pfeiffer Hi Pace 80), conversion kit, cable and other small components. Note: the rotary vacuum pump used with the LV version will be required to “back” the internally mounted turbomolecular pump.
SKU: 200000Price On Request £0.00 Add to basketAdd to QuoteWithin your QuoteAdd to QuoteHigh vacuum (HV) upgrade kit I
Upgrade kit for converting CCU-010 LV to high vacuum CCU-010 HV specification. Includes turbomolecular pump (Pfeiffer Hi Pace 80), conversion kit, cable and other small components. Note: the rotary vacuum pump used with the LV version will be required to “back” the internally mounted turbomolecular pump.
£0.00Price On Request
